hot saleCHCNAV X15 /I89 GNSS Receiver RTK with 1408 Channels Rover GNSS RTK and Land Surveying Instruments GPS RTK
Original price was: $2,031.15.$1,579.78Current price is: $1,579.78.
16 people are viewing this product right now
🔥 10 items sold in last 3 hours
You may also like
-
-
-
-
Price range: $10.07 through $19.65 -
Price range: $34.20 through $83.52 -
- Brand Name: NoEnName_Null
- Origin: Mainland China
- Hign-concerned Chemical: None
- DIY Supplies: Electrical
- Certification: CE
- warranty: 1 year
- customized support: OEM, ODM, OBM
- place of origin: Shanghai, China
- brand name: CHCNAV
- model number: X15/i89
- Product name: CHC X15 /I89 GPS
- Channels: 1408 channels
- GPS: L1C, A, L2C, L2P(Y), L5
- Galileo: E1, E5a, E5b, E6*
- PPP: B2b-PPP
- Weight: 750 g (1.65 lb)
- Till angle: 0-60°
- Humidity: 100% non-condensation
- Drop: Survive a 2-meter pole-drop
- Power consumption: Typical 2.2 W
My friend, welcome to our store, if you need other models of this product, please contact me, I will send the product link for you to buy! For some heavy goods, the shipping cost is not accurate. Please contact us for details. And welcome to add my WHATSAPP (+8615575894035)，My Email is dy31415926035@163.com .
#detail_decorate_root .magic-0{width:750px}#detail_decorate_root .magic-1{overflow:hidden;width:750px;height:120px;margin-top:0;margin-bottom:0;margin-left:0;margin-right:0}#detail_decorate_root .magic-2{margin-top:-19px;margin-left:3px;width:750px;height:137px}#detail_decorate_root .magic-3{vertical-align:top}#detail_decorate_root .magic-4{vertical-align:top;display:block;padding-right:4px;box-sizing:border-box;padding-left:4px}#detail_decorate_root .magic-5{vertical-align:top;padding-bottom:4px;box-sizing:border-box;padding-top:4px}#detail_decorate_root .magic-6{padding:0;margin:0;white-space:pre-wrap;font-size:14px}#detail_decorate_root .magic-7{text-align:center}#detail_decorate_root .magic-8{font-family:inherit;font-size:inherit;font-style:inherit;font-variant-ligatures:inherit;font-variant-caps:inherit}#detail_decorate_root .magic-9{margin-bottom:10px;line-height:0}#detail_decorate_root .magic-10{margin-bottom:0}#detail_decorate_root .magic-11{position:relative;width:100%}#detail_decorate_root .magic-12{width:750px;border-collapse:collapse}#detail_decorate_root .magic-13{min-height:28px;padding:5px 10px;width:299px;min-height:28px;box-sizing:content-box}#detail_decorate_root .magic-14{display:none}#detail_decorate_root .magic-15{min-height:28px;padding:5px 10px;width:405px;min-height:28px;box-sizing:content-box}#detail_decorate_root .magic-16{min-height:28px;padding:5px 10px;width:300px;min-height:28px;box-sizing:content-box}#detail_decorate_root .magic-17{min-height:28px;padding:5px 10px;width:404px;min-height:28px;box-sizing:content-box}#detail_decorate_root .magic-18{margin-bottom:10px;overflow:hidden}#detail_decorate_root .magic-19{overflow:hidden;width:750px;height:847px;margin-top:0;margin-bottom:0;margin-left:0;margin-right:0}#detail_decorate_root .magic-20{margin-top:-2px;margin-left:-3px;width:750px;height:847px}#detail_decorate_root .magic-21{overflow:hidden;width:750px;height:1424px;margin-top:0;margin-bottom:0;margin-left:0;margin-right:0}#detail_decorate_root .magic-22{margin-top:0;margin-left:0;width:750px;height:1424px}#detail_decorate_root .magic-23{overflow:hidden;width:750px;height:1596px;margin-top:0;margin-bottom:0;margin-left:0;margin-right:0}#detail_decorate_root .magic-24{margin-top:-10px;margin-left:-3px;width:750px;height:1596px}#detail_decorate_root .magic-25{overflow:hidden;width:750px;height:884px;margin-top:0;margin-bottom:0;margin-left:0;margin-right:0}#detail_decorate_root .magic-26{margin-top:0;margin-left:0;width:750px;height:884px}#detail_decorate_root .magic-27{overflow:hidden;width:750px;height:1001px;margin-top:0;margin-bottom:0;margin-left:0;margin-right:0}#detail_decorate_root .magic-28{margin-top:0;margin-left:0;width:750px;height:1001px}#detail_decorate_root .magic-29{overflow:hidden;width:750px;height:1471px;margin-top:0;margin-bottom:0;margin-left:0;margin-right:0}#detail_decorate_root .magic-30{margin-top:0;margin-left:0;width:750px;height:1471px}#detail_decorate_root .magic-31{overflow:hidden;width:750px;height:154px;margin-top:0;margin-bottom:0;margin-left:0;margin-right:0}#detail_decorate_root .magic-32{margin-top:0;margin-left:0;width:750px;height:154px}#detail_decorate_root .magic-33{font-size:18px}
CHC X15 /I89 GNSS Receiver RTK with 1408 channels Rover GNSS RTK and Land Surveying Instruments GPS RTK
The i89 GNSS delivers unmatched performance with its 1408 channels and integrated SoC for full constellation tracking. Robust algorithms increase fix rates by 15%, even in harsh environments. CHCNAV and ionospheric interference rejection technology provide an outstanding 96% reliable fix rate, ideal for low latitude regions with high ionospheric activ ity. Its
narrow-band multipath mitigation ensures accurate RTK measurements, and its hybrid GNSS engine provides unmatched accuracy and reliability.
narrow-band multipath mitigation ensures accurate RTK measurements, and its hybrid GNSS engine provides unmatched accuracy and reliability.
|
GNSS Performance
|
|
|
|
Channels
|
1408 channels
|
|
|
GPS
|
L1C/A,L1C,L2C,L2P,L5
|
|
|
GLONASS
|
G1,G2,G3
|
|
|
Galileo
|
E1,E5a,E5b,E6*
|
|
|
SBAS
|
L1C/A*
|
|
|
QZSS
|
L1C/A,L1C,L2C,L5
|
|
|
IRNSS
|
L5*
|
|
|
BDS
|
B1I,B2I,B3I,B1C,B2a,B2b*
|
|
|
GNSS Accuracies
|
|
|
|
Real time kinematics (RTK)
|
Horizontal: 8 mm + 1 ppm RMS
Vertical: 15 mm + 1 ppm RMS Initialization time: <10 s Initialization reliability: >99.9% |
|
|
Post-processing kinematics (PPK)
|
Horizontal: 3 mm + 1 ppm RMS
Vertical: 5 mm + 1 ppm RMS |
|
|
Post-processing static
|
Horizontal: 2.5 mm + 0.5 ppm RMS
Vertical: 5 mm + 0.5 ppm RMS |
|
|
Code differential
|
Horizontal: 0.4 m RMS
Vertical: 0.8 m RMS |
|
|
Autonomous
|
Horizontal: 1 m RMS
Vertical: 1.5 m RMS |
|
|
Positioning rate
|
1 Hz, 5 Hz and 10 Hz
|
|
|
Time to first fix
|
Cold start: < 45 s
Hot start: < 10 s Signal re-acquisition: < 2s |
|
|
IMU update rate
|
200 Hz
|
|
|
Tilt angle
|
0-60°
|
|
|
RTK tilt -compensated
|
Additional horizontal pole-tilt
uncertainty typically less than 10 mm + 0.7 mm/° tilt |
|
|
Hardware
|
|
|
|
Size (L x W x H)
|
133.5mm*80mm
|
|
|
Weight
|
0.73 kg (1.60 lb)
|
|
|
Front panel
|
4 LED, 2 physical buttons
|
|
|
Environment
|
Operating: -40°C to +65°C
(-40°F to +149°F) Storage: -40°C to +85°C (-40°F to +185°F) |
|
|
Humidity
|
100% condensation
|
|
|
Ingress protection
|
IP67 waterproof and dustproof,protected from temporary immersion to depth of 1 m
|
|
|
Shock
|
Survive a 2-meter pole drop
|
|
|
Tilt sensor
|
Calibration-free IMU for pole-tilt compensation.
Immune to magnetic disturbances.E-Bubble leveling |
|
|
Communication
|
|
|
|
Wi-Fi
|
802.11 b/g/n, access point mode
|
|
|
Bluetooth
|
V4.2
|
|
|
Others
|
NFC
|
|
|
Ports
|
1 x USB Type-C port(external power, data download, firmware update)
1 x UHF antenna port (TNC female) |
|
|
UHF radio
|
Standard Internal Tx/Rx:
410 -470 MHz Transmit Power: 0.5 W, 1W Protocol: CHC, Transparent, TT450, Satel Link rate: 9,600 bps to 19,200 bps |
|
|
Data formats
|
RTCM 2.x, RTCM 3.x,
CMR input /output HCN, HRC, RINEX 2.11, 3.02 NMEA 0183 output NTRIP Client, NTRIP Caster |
|
|
Data storage
|
8 GB internal memon
|
|
|
Electrical
|
|
|
|
Power consumption
|
Typical 4 W (depending on user settings)
|
|
|
Li-ion battery capacity
|
Built-in non-removable battery 6800 mAh, 7.4 V
|
|
|
Operating time on internal battery
|
UHF I4G RTK Rover: up to 14.5 h UHF RTK Base: up to 6.5 h Static: up to 18 h
|
|
|
Certifications
|
|
|
|
CE Mark; FCC Part 15 Subpart B Class B; NGS Antenna Calibration
|
|
|
